The IStoragE3 B5-S2 model is a modern modular battery based on LiFePO4 technology. With a capacity of 5 kWh and scalability up to 40 kWh, it is perfect for residential and commercial systems. Its compact size and IP65 protection rating allow for both wall-mounted and floor-mounted installations. The integrated energy management system ensures optimal performance, while natural cooling simplifies maintenance.
- Technical specifications:
- Cell technology: LiFePO4
- Battery energy capacity: 5 kWh
- Usable capacity: 5 kWh
- Scalable capacity range: 5–40 kWh
- Rated power: 4 kW
- Voltage range: 650–900 V
- Maximum charge/discharge current: 6.15 A
- Dimensions: 800 × 380 × 238 mm
- Weight: 52 kg
- Charge temperature: 0–50 °C
- Discharge temperature: -20–50 °C
- IP rating: IP65
- Communication interfaces: RS485, CAN
- Cooling type: natural cooling
- Certification: IEC 62619, IEC 60730, UN 38.3
- Installation methods: wall-mounted or floor-mounted
